Moving Head LED Outdoor Strobe Light

JJDC1
OEM&ODM Available
Built-in W-DMX module optional
Local stock warehouse for fast delivery with free Duty
Share:
Contact Us

Moving Head LED Outdoor Strobe Light

Video&Image

Specification

Technical Sheet

Strobe Panel LEDs

  • LED Type: 5050 0.5W RGB 3in1 LEDs
  • LED Count: 480
  • LED Colors: RGB
  • LED Segments: 8 (2 x 4)



Strobe Tube LEDs

  • LED Type: 3535 5W 6500K LEDs
  • LED Count: 144
  • LED Colors: Cool-White
  • LED Segments: 4



Movement

  • Resolution: 8-16 Bit
  • Tilt (Degrees): 185°



Control

  • Control Modes: 9CH / 14CH  / 42CH
  • Display: Illuminated graphic LCD
  • Protocol: USITT DMX-512, RDM
  • RDM: Bidirectional communication
  • Wireless DMX: 2.4 GHz W-DMX™ (optional)
  • Cooling: Temperature controlled, overheating protection



Effects

  • Dimmer: 0-100% electronic
  • Shutter: electronic, max. 20 Hz
  • Internal Effects: LED Macro Effects



Connectors

  • Signal connection: Seetronic IP65 XLR 5-Pin or 3-Pin In/Out Power Input: Seetronic powerCON TRUE1 In/Out



Operating Condtions

  • Mains voltage: 100-240V AC / 50-60Hz
  • Power: 1000W
  • Maximum ambient temperature: -30°C / 86°F, 50°C / 122°F Operating Position: any



Mounting Options

  • Standing: Rubber feet
  • Hanging: Omega-Bracket
  • Safety wire attachment: foldout eyelets



Shipping

  • Single fixture: cardboard (inner and outer cartons) Tourpack: 4-way Flight Case



Housing Colors

  • Standard colors: black



Packing

Dimensions & Weight

  • Length: 482 mm / 18.9 in
  • Width: 178 mm / 9.0 in
  • Height (head horizontal): 243 mm / 9.5 in



Weight

  • N.W: 10 kg
  • G.W: 12.5 kg
