Light source specifications:

• 7x60 watt R G B W OSRAM high brightness LEDs for the main light source
• 70 auxiliary light sources, 0.5 watt R G B
• Rated life 50000 hours
• Focusing:
• DMA linear focusing, ultra smooth adjustment of focal length. Beam angle 3-45 degrees

Rotation angle:

• Driven by a three-phase stepper motor, it is fast, quiet, and has an automatic return function.
• 540 ° horizontally and 270 ° vertically

Control method:

• International standard DMX512 signal/master-slave/automatic, 3-core interface+5-core interface with RDM function, which can be used to dial address codes
• 25CH and 93CH channel modes

Other functions:

• Adjustable horizontal and vertical speeds
• Adopting a powerful silent fan, displaying LED temperature, reducing power due to overheating,
• ensuring LED service life Modular structure for easy maintenance

Shell material/protection level/package size weight:

• High temperature/UV resistant engineering plastic protection grade: IP20
• Package size: 47*38*65CM, weight:18kg
